EMAGE:3952

Wnt3 wingless-related MMTV integration site 3 ( MGI:98955)
TS19 (11.5 dpc)
in situ hybridisation

Data Images


3D reconstructed object showing signal.	All sections along the X-axis, as movie.	All sections along the Y-axis, as movie.	All sections along the Z-axis, as movie.	Photograph prior to 3D imaging.

View 3D opt image:
Download 3D images in woolz format
Expression pattern clarity:
Find spatially similar expression patterns:

Notes:

This is a traditionally produced wholemount in situ hybridisation stained using alkaline phosphatase + NBT/BCIP. It has been imaged using Optical Projection Tomography using visible light. In the OPT images, the signal is visible as the brightest regions.

Expression Pattern Description

Spatial Annotation:

Annotation colour key:

	strong
	moderate
	weak
	possible
	not detected

3D mapping

View mapped 3D expression image

Download individual expression domains:

3952_voxel_strong_3D_1.wlz

3952_voxel_possible_3D_1.wlz

(what is wlz format?)

Download all expression domains:

EMAGE:3952_all_domains.zip

Find spatially similar expression patterns:

Morphological match to the template:

Text Annotation:

Structure

Level

Pattern

Notes

embryo

detected

Annotation Validation:

EMAGE Editor

Detection Reagent

Type:	in situ hybridisation probe
Identifier:	Wnt3 probeA
Entity Detected:	Wnt3, wingless-related MMTV integration site 3 ( MGI:98955)
Sequence:	sense strand is shown >Wnt3 probeA CGACTCCCATTTAAATTGGACATACCTTGTCGTTCTGAGAAAAGCCATAGATAGGTGTAGCTGGGATGTA GTGATGGGGAGGCCCCTGGCCAACAGTGGGAGCAAGATCTTGAGTTTTGAAGACCTCAGAGTTCTGGGCG GCCTGGGAAGCCATCTGCAGAACAGAGTTCCTTGTGGGCTCCTGTTTTCGCTAGCCCTGTTCTGCCCTGG AGCGACAGTCAGATCTCCACGCCCCTTTCTGTTGTTCTACAGTGTCCACCTTTACTACGCGTTTTTTTTT TTTTTTTCATGATGACCTTGTAAATAGGTCAGATGTGGAGGCAGGTCTCTTCTGGCTCCATCCACCACAC CCAGAAAGAATGGGCTGCTCTGCCCTTCTCAGCCTTGCTAACCAGCAGACACCGAGGAGAGCAGCGGGGC ACCTTAGAGAGCAATCTAAACATGGTTGGCAGGTGGGGAGGGTAAAGAGTCCCACTTCCTTTGTGTTAGA AGGCAGACTACCCTGCGTCCTTTTCTCCCATTGGCTGAAGTAACCAGAAAGACAAGAGATCCTTAACAAG CCCTTCTTCCCACTTGTAAAAGGGATAGCCTATCTCAGTTCCCAAGGATCTGGATTAGATAGATATTCAA AAGAGGCAAGCAGCGAATGGAGGCAGCTCCCAGCTCTGTTCCCGACGCATGATGGTACTGGCTGGGTTTA GTAAGGTGGGTGGGGCTGCACGGATCAATCCATCAACTCCGTCTTAAGGAGAATCAGAAAGAGGAGATAA AATGGGGGAATGGGGCAGAACAAAGAATTTGTCCTTTCCCGCTTCTGTCTAGGGTCTGCTAATGCTGGCT TGACGAGGGGTCAGCCACTTCTTTCCTGTTGTGCAGTTGGCTTGCCAAGCAGGCTCCAGTAGGCCCTTGC CTGCACTCTCTACCATGTGACCATGAGCACTGCTCTAGGGACACCTCCCATCCCTTCCTAGCACCCCAAA TGCCCCTTCCCATCTCTCCTTCCAGAAGTTGGAAATCAAGTCAACTGGATAACGCTTGTGTGAGACACTT GAGCAGAACGGATACAACAATTTACAAGTCTCTTCATATCTATGTATTCTATATTAAAAGTGATAAAGTC ATGTTTCCGGGGCGTATTCAAGTAGCTGACAAGTAATTATTTAATAATAGTACATGAGCGCATTGTAATT ATCCTCGCCATAGTCAGGTAATAGCATCCAATGGGAGGTCCCTACCAACCTGCTGTATCCAAAGTTTTGT AAAAAGTTGTAGAAGTTGTTGATCTTTTTGATTTTATATTCAAAAAGTCTCTTTTTATAAATATTATTTA TTATACAATGTATATACCTTTGAGTTAACTAAGATTATATATTATATAAATATATATATATT
	nt 1609 - nt 3000 of NM_009521.1
Notes:	The template used to generate the Wnt3 probe used in this study was obtained from P. Salinas. Probe was transcribed from the entire insert. The insert sequence of the clone has been verified by Summerhurst and Murphy (it spans nt 1609-3000 of the Wnt3 cDNA RefSeq NM_009521.1).
Chemistry:	RNA
Strand:	antisense
Label:	digoxigenin

Specimen

Organism:	mouse
Strain:	CD1
Age:	11.5 dpc
Theiler Stage:	TS19
Mutations:	none (wild-type)
Preparation:	opt

Procedures

Fixation:	4% paraformaldehyde
Embedding:	agarose
Staining procedure:	alkaline phosphatase + NBT/BCIP

General Information

Authors:	Kristen Summerhurst, Paula Murphy
Principal investigator:	Paula Murphy, Trinity College Dublin, Zoology Department, Dublin, Ireland 2
Submitted by:	Kristen Summerhurst, Trinity College Dublin, Zoology Department, Dublin, Ireland 2
Experiment type:	non-screen
Links:	Ensembl same gene
